Create a tree-style dendrogram plot

Creates a classical node-link tree diagram (dendrogram) using geom_segment() from the segment data in a sunburst_data object.

Usage

ggtree(
  sb,
  colour = "black",
  linewidth = 0.5,
  show_labels = TRUE,
  label_size = 3,
  label_colour = "black",
  rotate = TRUE,
  polar = FALSE,
  blank = TRUE,
  show_scale = FALSE,
  scale_length = 0,
  ...
)

Arguments

sb

A sunburst_data object from sunburst_data().

colour

Line colour for tree segments. Default "black".

linewidth

Line width for tree segments. Default 0.5.

show_labels

Whether to display leaf labels. Default TRUE.

label_size

Text size for leaf labels. Default 3.

label_colour

Text colour for leaf labels. Default "black".

rotate

If TRUE (default), apply coord_flip() for horizontal layout (root left, leaves right).

polar

If TRUE, apply coord_polar() for circular layout. Overrides rotate.

blank

If TRUE (default), apply theme_void().

show_scale

If TRUE, display a scale bar indicating branch-length units. Default FALSE.

scale_length

Length of the scale bar. When 0 (default), auto-computed as one tenth of the total tree depth.

...

Passed to geom_segment().

Value

A ggplot object.

Details

Three layout modes are available:

• Horizontal dendrogram (default): rotate = TRUE, polar = FALSE. Root at left, leaves at right.

• Vertical dendrogram: rotate = FALSE, polar = FALSE. Root at top, leaves at bottom.

• Circular (radial) tree: polar = TRUE. Root at centre, leaves around circumference with leader lines and rotated labels.

Note

The Bioconductor package ggtree also exports a ggtree() function. If both packages are loaded, use ggsunburstR::ggtree() to disambiguate.

See also

sunburst() for polar sunburst plots, icicle() for rectangular layouts.

Examples

sb <- sunburst_data("((a, b, c), (d, e));")
ggtree(sb)

ggtree(sb, polar = TRUE)
